25mm PM Stepper Motor with Non-captive Shaft

Basic Info


Model No.: 25BYZ-B linear pm stepper motor/ step angle 15° with non-cap


Product Description

Product Code: 25mm PM Stepper Motor with Non-captive Shaft



25BYZ-B linear pm stepper motor/ step angle 15° with non-cap

Features:

The stator section of our 25mm series PM stepper motors consists of coils, stator yoke, in/out terminal and stators molded together in one piece by plastic resin.

PM stepper motors are assembled simply by combining the stator with rotors of cylindrical permanent magnets. For some specific applications, our PM stepper motor has been updated and you see that the conversion of rotary to linear motion takes place with the motor body itself via the integrated leadscrew and nut, therefore eliminating the use of belts and pulleys, couplings and other mechanical transmission components.

The non captive leadscrew travels through the motor enabling the shortest possible footprint of any linear actuator available on the market today. Being set at the step angle of 15 degress, our non-captive linear PM stepper motors are available with options both in winding phase and working voltage and currently the stroke is as long as 40mm.

Applications:

Our non-captive linear PM stepper motors have proved ideal in such applications as semiconductor handling machines, medical and laboratory equipment.

Specification:

Model

Step Angle

(°)

No. of Phase

Voltage

(VDC)

Current

(A)

Resistance

(Ω)

Inductance

(mH)

Step Avail

(mm)

Pull Torque

(N.m)

Journey

(mm)

25BYZ-A04

15

4

5

0.23

22

4.3

0.0417

7

12

25BYZ-B01

15

2

12

0.23

53

23.5

0.0417

20

12
