28mm PM Stepper Motor with Captive Shaft

Basic Info


Model No.: 28BYZ-A linear pm stepper motor/ 5v or 24v linear motor for valve actuators


Product Description

Product Code: 28mm PM Stepper Motor with Captive Shaft



28BYZ-A linear pm stepper motor/ 5v or 24v linear motor for valve actuators



Features:

In the family of 28mm PM stepper motors, the motor shown in the picture is one of the product members, which has demonstrated before our customers the new style to be owed with a captive linear shaft.



Being in a version of 28mm diameter, our PM stepper motor internally converts rotary linear motion via a rotating nut and a leadscrew. This construction will eliminate the need for other rotary-to-linear conversions such as belts and pulleys, rack and pinions, or external ball screws.



They are greatly liked by the application engineers because of simple motion designs, lower production cost and enhanced product life. Standard models are normally available from stock, but we can make specials on request.



You can contact us freely to know more details about our 28mm captive linear PM stepper motors such as the step angle, the travel at full step and standard screw length and etc, among which some of them can be customized to fit your OEM applications.



Applications:

They can meet your requirements in different applications such as pumps, robotics and heat supply facilities as well as valve actuators.



Specification:

Model

Step Angle

(°)

No. of Phase

Voltage

(VDC)

Current

(A)

Resistance

(Ω)

Inductance

(mH)

Step Avail

(mm)

Pull Torque

(N.m)

Journey

(mm)

28BYZ-09

15

2

5

0.46

10.8

/

0.0417

40

40

28BYZ-A01

15

2

24

0.16

150

85

0.0417

65

12
